Mitsubishi #CM400DY-24A New Instock

CM400DY-24A CM400DY-24A CM400DY-24A CM400DY-24A

The CM400DY-24A is an Insulated Gate Bipolar Transistor (IGBT) module designed for use in high-power applications such as motor drives, servo drive amplifiers, and uninterruptible power supplies. Its compact package and P.C. board mount make it easy to integrate into a variety of systems. The device features a low VCE(sat) and is capable of withstanding high collector currents up to 400A and collector-emitter voltages up to 1200V. The module has a collector power dissipation rating of 27100W and an operating junction temperature of +150°C. The CM400DY-24A is capable of withstanding storage temperatures ranging from -40 to +125°C, and has a recommended mounting screw torque of 3.5 * 1 N·m.

· Inverter for motor drive
· AC and DC servo drive amplifier
· Uninterruptible power supply
Maximum ratings and characteristics
.Absolute maximum ratings (Tc=25°C unless without specified)
Collector-Emitter voltage Vces:1200V
Gate-Emitter voltage VGES:±20V
Collector current Ic:400A
Collector current Icp:800A
Collector power dissipation Pc:27100W
Collector-Emitter voltage VCES:2500V
Operating junction temperature Tj:+150°C
Storage temperature Tstg :-40 to +125°C
Mounting screw torque 3.5 *1 N·m

400A/1200V/IGBT/2U; N Channel 400 A 1.2 kV 2.71 kW 1.2 kV Module
